Design

• Bevelled front edge
• 80 cm: space for 5 pots or pans.

Flexibility of cooking zones

• Combi zone
• : use bigger cookware by connecting two classic cooking zones into one large zone.
• Cooking zone front left: 180 mm, 1.8 KW (max. power 3.1 KW)
• Cooking zone rear left: 145 mm, 1.4 KW (max. power 2.2 KW)
• Cooking zone middle: 240 mm, 2.2 KW (max. power 3.7 KW)
• Cooking zone rear right: 190 mm, 210 mm , 2.2 KW (max power 3.7 KW)
• Cooking zone front right: 190 mm, 210 mm, 2.2 KW (max. power 3.7 KW)

Usage convenience

• Touch control: control the power with imprinted +/- touch buttons.
• Variable 17-stage power settings for each zone: precisely adapt the heat with 17 power levels (9 main levels and 8 intermediate levels).
• Keep warm function: Keep Warm Function: keep dishes warm at preset low power level.
• Timer with automatic shut off for all zones
• : switches off the cooking zone at the end of the time set (e.g. for boiled eggs).
• LED timer for each zone with switch off function and acoustic signal
• : an alarm sounds at the end of the time set (e.g. for pasta).

Time saving & efficiency

• Power Boost function for all zones
• : boil water faster thanks to 50% more energy than at the highest standard level.
• 2-steps: increase or decrease the power level simply by moving the pot forwards or backwards.
• QuickStart function: when switching on, the hob automatically selects the cooking zone with cookware (when placed on a zone whilst the hob is off).
• ReStart function: in case of unintentional switch-off, this feature restores all previous settings by switching on the hob again within 4 seconds.

Safety

• 2 stage residual heat indicators: indicates which cooking zones are still hot or warm.
• Control panel lock: prevent unintended activation of the hob.
• Control panel suspension: wipe overboiled liquids without unintentionally changing settings (blocking all touch buttons for 30 seconds).
• Main switch: switch off all cooking zones at the touch of a button.
• Safety cut out facility: for safety reasons, heating stops after a preset time if not used (possible to customise).
• Energy consumption display: shows the electricity consumption of the last cooking process.

Installation

• Dimensions of the product (HxWxD mm): 51 x 802 x 522
• Required niche size for installation (HxWxD mm) : 51 x 750 x (490 – 500)
• Min. worktop thickness: 16 mm
• Connected load: 7.4 KW
• 4.6kW power output (20A); current management options for 16A, 13A or 10A connection: limit the maximum power if needed (depends on fuse protection of electric installation).
• Power cord: 1.1 m, Cable included in packaging
